2Water Hybrid

2WHybrid carrusel

2Water Hybrid - Hybrid Sistem

What is 2Water Hybrid?

It is a heat pump with a Hybrid Panel for the production of Domestic Hot Water and electricity. This captures the energy contained in the ambient thanks to the heat transfer fluid (glycolated water) that circulates inside the panel, and which also produces electrical energy thanks to hybridization with the photovoltaic panel.

Savings up to:
0%
ACS y electricidad

DHW & ELECTRICITY

With the combination of photovoltaic and thermal energy, this system provides Domestic Hot Water and electricity simultaneously.

Ahorro garantizado

ECONOMIC SAVINGS

Reduces energy costs compared to using separate systems. This means savings on bills and amortization of the installation.

Eficiencia y ahorro

MORE ENERGY EFFICIENCY

Reduces energy consumption thanks to its ability to make the most of solar energy and produce both heat and electricity.

Máxima calidad

MAXIMUM QUALITY

System that improves the energy efficiency of the home, with a tank made of stainless steel, advanced control, thick insulation that reduces noise.

Hybrid Panel

TWO TECHNOLOGIES DOUBLE THE POWER

The Hybrid Panel combines two technologies: photovoltaic and thermal, generating heat for DHW and electricity in the same panel. The photovoltaic upper part converts light into electricity, while the thermal inner part captures ambient energy day and night. This combination maximizes efficiency and reduces energy costs.

Maximum photovoltaic efficiency
650w power

State of the art photovoltaic production with the best solar utilization that exists on the market.

One system, double benefit:

This heat pump with a hybrid panel takes advantage of both solar thermal energy and solar photovoltaic energy, allowing it to generate electricity and heat water in an efficient and sustainable way. By installing a hybrid system, you will be able to reduce your dependence on the electrical grid and fossil fuels, thanks to this, you will achieve savings on your energy bill in the long term. de energía a largo plazo.

Additionally, hybrid panels take up less space than installing separate systems for each function, which is especially useful if you have limited space on your property or roof. By reducing the carbon footprint of your home or building, you will be helping to protect the environment.

That is why this heat pump with hybrid panel is an innovative and efficient solution for the generation of electricity and domestic hot water in a single system. Take advantage of the power of the sun and make your installation a more sustainable place!

Sistema sostenible

Sustainable system

2 in 1

2 Functions in 1 system

Rapida amortización

Quick payback

Ahorra espacio

Save roof space

Aumenta el valor de la propiedad

+ Property value

Increases performance by up to 40%

Hybrid Panel

When the panels reach temperatures of up to 75°C under intense solar radiation, they cause a 25% drop in performance.

Faced with this situation, the Efitherma Hybrid Panel with heat pump allows the panels to be cooled down to -15°C. This cooling not only mitigates the effects of photovoltaic overheating, but also increases panel performance by up to 40% compared to one at 75°C, thus offering an innovative and efficient solution to optimize energy generation and extend useful life of the panels.

Más 40%

605w power

With the most powerful photovoltaic panel on the market you will get:

  • Greater production of electrical energy that can be used both for the electrical needs of the building and for the operation of the heat pump.
  • They can be installed in position horizontal or vertical

More durability

The hydraulic circuit of the hybrid panel prevents overheating of the photovoltaic base. It is composed of water, an element that makes this technology efficient and environmentally friendly.

  • It refreshes the photovoltaic base of the panel, extending its useful life and improving electrical and thermal performance.

Two in one

We offer a 100% renewable system in a closed circuit that combines:

  • Photovoltaic electrical production in the hybrid panel
  • DHW Production using the 2Water heat pump.
  • Heat capture thanks to the hydraulic circuit of the panel.

Ideal for large consumption

Choose the energy of the future

  • Hoteles
    Hotels
  • Centros de salud
    Hospitals
  • Centros educativos
    Schools
  • Salón de eventos
    Event hall
  • Residenciales
    Residential housing
  • Casas unifamiliares
    Single - Family houses
  • Campings
    Campings
  • Granjas
    Farms
  • Industria
    Factories
  • Centros deportivos
    Sport centers
  • Car washes
  • Residencias de ancianos
    Nursing homes

Available Capacities

250 & 500 LITERS

Technical Data

250 litre model

Technical data of the equipment

Extraction cycle

XL

Nominal power DHW (14ºC)*

1834w

Nominal consumption (14ºC)*

571w

SCOP DHW (14ºC)*

3,21

Thermal power support system

1500w

Refrigerant gas

R134a

* Data expressed for a heating temperature of 55ºC and cold water temperature of 10ºC according to the UNE-EN16147 standard.

* SCOP depending on the climatic zone

Dimensions, weight and connections

Equipment dimensions (AxBxC)*

1785 x 550 x 601 mm

Empty equipment weight

107,5Kg

Panel dimensions (AxBxC)*

2094 x 35 x 1038 mm

Hydraulic connections DHW**

M 3/4 – 3/4 Pulg.

Hydraulic connections 2Water systems**

F 1/2 – 1/2 Pulg.

Hydraulic connection between panels***

20 mm

* A = Height / B = Depth / C = Width

** M (Inlet and outlet of the equipment’s hydraulic connection in Male).

** F (Inlet and outlet of the equipment’s hydraulic connection in Female).

*** Press connection between panels with 20mm tube.
