HydroConnect 180+75 is the combination of a 75 litres buffer tank and a 180 litres DHW tank in a single compact unit. It includes different connections located on the top to connect it to the DHW system, the air conditioning system and the heat pump or chiller (aerothermal, geothermal, etc.), for easy and quick installation.
HydroConnect incorporates different Plug & Play outputs located on the top for quick and easy installation.
This combined buffer tank is specifically designed to be combined with a heat pump (air source heat pump, geothermal heat pump, etc.).
Made from high quality materials, it guarantees a long service life, maintaining safety standards at all times.
A single device for storing air conditioning and DHW water, avoiding the need to install multiple tanks or systems.
Unlike a conventional inertia tank, HydroConnect can store hot water and water used for heating.
Thanks to the incorporation of different outputs located on the top of the equipment, it can be easily connected to the DHW system, the air conditioning system and the heat pump or chiller (aerothermal, geothermal, etc.), making its installation much simpler and faster.
Discover the differences between a conventional buffer tank and Efitherma’s HydroConnect:
HydroConnect is designed to be quick and easy to install, requiring fewer connections than a traditional system with separate tanks. It also operates with an efficiency oriented approach, reducing energy consumption and the costs associated with the production of DHW and air conditioning.
The differences with respect to a conventional inertia tank are many, some of the most notable are: it’s dual functionality and multiple applications.
It’s stainless steel tanks, together with the titanium electronic anode against impressed current corrosion, ensure greater durability and efficiency in its operation. It also includes protection against legionella bacteria to ensure the healthiness of the stored water.
Surface of the inner coil
9 m²
Máx. Temp. DHW Storage
80 ºC
Max. pressure of the DHW safety valve
6 bar
Max. pressure buffer tank safety valve
3 bar
Capacity of the DHW expansion vessel
5 Liters
Type of tank insulation
Injected polyurethane
Hydraulic connection inlet/outlet heating
1” Female
Hydraulic connection inlet/oulet heat pump
1” Female
Hydraulic connection inlet/outlet of the tank
3/4” Female
Equipment height
1925 mm
Equipment width
594 mm
Equipment depth
609 mm
HydroConnect 180+75 is the combination of a 75 litres buffer tank and a 180 litres DHW tank in a single compact unit. It includes different connections located on the top to connect it to the DHW system, the air conditioning system and the heat pump or chiller (aerothermal, geothermal, etc.), for easy and quick installation.
It incorporates different Plug & Play outputs located on the top for quick and easy installation.
Made from high quality materials, it guarantees a long service life, maintaining safety standards at all times.
This tank is specifically designed to be combined with a heat pump (aerothermal, geothermal, etc.).
A single device for storing air conditioning and DHW water, avoiding the need to install multiple tanks or systems.
Unlike a conventional inertia tank, HydroConnect can store hot water and water used for heating.
Thanks to the incorporation of different outputs located on the top of the equipment, it can be easily connected to the DHW system, the air conditioning system and the heat pump or chiller (aerothermal, geothermal, etc.), making its installation much simpler and faster.
Discover the differences between a conventional buffer tank and Efitherma’s HydroConnect:
HydroConnect is designed to be quick and easy to install, requiring fewer connections than a traditional system with separate tanks. It also operates with an efficiency oriented approach, reducing energy consumption and the costs associated with the production of DHW and air conditioning.
The differences with respect to a conventional inertia tank are many, some of the most notable are: it’s dual functionality and multiple applications.
It’s stainless steel tanks, together with the titanium electronic anode against impressed current corrosion, ensure greater durability and efficiency in its operation. It also includes protection against legionella bacteria to ensure the healthiness of the stored water.
